Full Specification

1. Model: Long Ran Hybrid UPS 1750
2. Capacity: 1600VA
3. Output Load Capacity: 1280 Watt (12V)
4. Lithium-ion Battery Supported (LiFepo4)
5. Wave Form: DSP Pure Sign Wave and microcontroller based
6. Input Voltage:100V AC – 295V AC
7. Output Voltage: 220+
8. Frequency: 50/60 Hz, Single Face
9. User selectable grid-charging enable or disable option
10. In-built heavy duty (PWM) solar charge controller 30AH
11. Maximum Solar Use: 1000Watt
12. Solar Panel Voltage-12V
13. Maximum Solar Voc-26V
14. In-built heavy PWM Charge Controller 30AH
15. Solar panel connection is parallel
16. Solar and grid charging current sharing for maximum solar usage
17. User satiable priority solar-battery-grid or solar-grid-battery
18. Inbuilt cold start & soft start function available
19. Protection
20. Overloading Protection- Yes
21. Overcharging Protection- Yes
22. Short Circuit Protection-Yes
23. lithium-ion (LiFePo4) Battery supported: Yes
24. Sinewave- 100% Pure Sine Wave
25. Power saving with no load shut down
26. Generator compatible
27. Battery deep discharge & over charge protection

Description

This Long Ran PCU-1750 is a Solar Hybrid Pure Sine Wave IPS/UPS with a rated power of 1600VA and 1280 Watts at 12V. It can power 8 fans, 10/12 energy lights, 1 TV and Wi-Fi router, CCTV and computer and options. It provides DSP pure sine wave technology and can have overloading, overcharging and short-circuit protection, bypass switch low voltage cut protection and full charge cut protection. It supports Lithium Ion (LiFePo4) batteries and this inverter has a silver transformer and an LCD & LED - Dual Big Display. It has in-built Heavy Duty (PWM) Solar Charge Controller, Max Solar Capacity-1000Watt, Solar Panel Voltage 12v, Max Solar VOC-26v, with in-built Heavy Duty PWM Charge Controller 30AH. It also has an input voltage range of 90-220 volts.
