SAKO SUNON PRO Hybrid 3.5kw MPPT Solar Inverter 24v

বিঃ দ্রঃ - ক্যাশ অন ডেলিভারির ক্ষেত্রে কুরিয়ার খরচ অগ্রিম পেমেন্ট করতে হবে.Model Name: PRO 3.5KVA- 100A-MPPTCapacity: 3.5KVA/3500WPower Factor: 1Operating Temp Range: -10~50C°Inverter ModeDC Input : 24VDC, 162AAC Output: 230VAC- 50/60Hz - 15.2ASolar Charger Mode MPPT & AC ChargerRated Power: 5000WNominal Operating Volt : 24VDCMin Solar Volt: 500VDCMPPT Volt Range: 120~450VDCOther ModeTransfer Time :10MS(UPS) 20MS(Appliances) Wave Form : Pure Shine WaveAC charge current : 60/100AIt can work with or without batteryAuto restart while AC is recoveringImportant note: directly guaranteed by Waked Electric Company, provided that the serial number is obtainedDescriptionSako brandModel Name: PRO 3.5KVA- 100A-MPPTCapacity: 3.5KVA/3500WPower Factor: 1Operating Temp Range: -10~50C°Inverter ModeDC Input : 24VDC, 162AAC Output: 230VAC- 50/60Hz - 15.2ASolar Charger Mode MPPT & AC ChargerRated Power: 5000WNominal Operating Volt : 24VDCMin Solar Volt: 500VDCMPPT Volt Range: 120~450VDCOther ModeTransfer Time :10MS(UPS) 20MS(Appliances) Wave Form : Pure Shine WaveAC charge current : 60/100AIt can work with or without batteryAuto restart while AC is recoveringImportant note: directly guaranteed by Waked Electric Company, provided that the serial number is obtainedFull SpecificationRated Power: 3500VA / 3500WFeaturesPure sine wave outputCold start functionBuilt-in MPPT solar charge controllerMAX PV Array Open Circuit Voltage: 450VSupport USB, RS485 monitoring function WIFI remote monitoring (optional)InputVoltage: 230VACSelectable Voltage RangeUPS: 170-280VACAppliances: 90-280VACFrequency Range; 50Hz/60Hz(Auto sensing)OutputAC Voltage Regulation (Batt. Model): 230VAC±5%Surge Power: 7000VAEfficiency(Peak): 90%Transfer Time:UPS: 10MSAppliances: 20MSPure sine wave Wave formNo load current: 1.0ABatteryBattery voltage: 24VDCLow battery alarming voltage: 22.0VDCLow battery cut off protection voltage: 21VDCLow battery recovery voltage: 23.0VDCFloating Charge Voltage: 27VDCOvercharge Protection: 32VDCMPPT Solar Charger & AC ChargerMaximum PV Array Power: 5000WMPPT Range at Operation Voltage: 120-450VDCMaximum PV Array Open Circuit Voltage: 500DCNumber of MPPT trackers/Max output current: 100AMaximum AC Charge Current: 60AMaximum Charge Current: 100AMaximum Efficiency: 98%Best Panel configuration300Wp x 9pcs x 36V (2700Wp) x 2ParallelPhysicalDimension D x W x H: 481 x 313 x 117mmNet Weight: 9.8 KgGross Weight: 11 KgOperating EnvironmentHumidity: 5 to 95% Relative Humidity (Non-condensing)Operation Temperature: -10°C-50°CDescriptionThe Sako Sunon Pro series is a hybrid inverter or charger that combines the functions of a 100A MPPT solar charger and a battery charger to generate electricity. It has Maximum Power Point Tracking (MPPT) technology that can be used to extract the maximum available power from the PV module under certain conditions. It has a smart LCD setting which can set working mode, charge current, charge voltage etc. It combines solar systems, AC utilities, and battery power sources to provide uninterrupted power. Also protects against overload, short circuit and deep discharge.

•
•
•
•

•
•
•
•

Details:

• Warranty
  2 Years Warranty

বিঃ দ্রঃ - ক্যাশ অন ডেলিভারির ক্ষেত্রে কুরিয়ার খরচ অগ্রিম পেমেন্ট করতে হবে.

•
  Model Name: PRO 3.5KVA- 100A-MPPT

• Capacity: 3.5KVA/3500W

• Power Factor: 1

• Operating Temp Range: -10~50C°

• Inverter Mode

• DC Input : 24VDC, 162A

• AC Output: 230VAC- 50/60Hz - 15.2A

• Solar Charger Mode MPPT & AC Charger

• Rated Power: 5000W

• Nominal Operating Volt : 24VDC

• Min Solar Volt: 500VDC

• MPPT Volt Range: 120~450VDC

• Other Mode

• Transfer Time :10MS(UPS) 20MS(Appliances)

•  Wave Form : Pure Shine Wave

• AC charge current : 60/100A

• It can work with or without battery

• Auto restart while AC is recovering

• Important note: directly guaranteed by Waked Electric Company, provided that the serial number is obtained

•
  Description

• Sako brand

• Model Name: PRO 3.5KVA- 100A-MPPT

• Capacity: 3.5KVA/3500W

• Power Factor: 1

• Operating Temp Range: -10~50C°

• Inverter Mode

• DC Input : 24VDC, 162A

• AC Output: 230VAC- 50/60Hz - 15.2A

• Solar Charger Mode MPPT & AC Charger

• Rated Power: 5000W

• Nominal Operating Volt : 24VDC

• Min Solar Volt: 500VDC

• MPPT Volt Range: 120~450VDC

• Other Mode

• Transfer Time :10MS(UPS) 20MS(Appliances)

•  Wave Form : Pure Shine Wave

• AC charge current : 60/100A

• It can work with or without battery

• Auto restart while AC is recovering

• Important note: directly guaranteed by Waked Electric Company, provided that the serial number is obtained

•
  Full SpecificationRated Power: 3500VA / 3500W

• Features

• Pure sine wave output

• Cold start function

• Built-in MPPT solar charge controller

• MAX PV Array Open Circuit Voltage: 450V

• Support USB, RS485 monitoring function WIFI remote monitoring (optional)

• Input

• Voltage: 230VAC

• Selectable Voltage Range

• UPS: 170-280VAC

• Appliances: 90-280VAC

• Frequency Range; 50Hz/60Hz(Auto sensing)

• Output

• AC Voltage Regulation (Batt. Model): 230VAC±5%

• Surge Power: 7000VA

• Efficiency(Peak): 90%

• Transfer Time:

• UPS: 10MS

• Appliances: 20MS

• Pure sine wave Wave form

• No load current: 1.0A

• BatteryBattery voltage: 24VDC

• Low battery alarming voltage: 22.0VDC

• Low battery cut off protection voltage: 21VDC

• Low battery recovery voltage: 23.0VDC

• Floating Charge Voltage: 27VDC

• Overcharge Protection: 32VDC

• MPPT Solar Charger & AC ChargerMaximum PV Array Power: 5000W

• MPPT Range at Operation Voltage: 120-450VDC

• Maximum PV Array Open Circuit Voltage: 500DC

• Number of MPPT trackers/Max output current: 100A

• Maximum AC Charge Current: 60A

• Maximum Charge Current: 100A

• Maximum Efficiency: 98%

• Best Panel configuration

• 300Wp x 9pcs x 36V (2700Wp) x 2Parallel

• Physical

• Dimension D x W x H: 481 x 313 x 117mm

• Net Weight: 9.8 Kg

• Gross Weight: 11 Kg

• Operating Environment

• Humidity: 5 to 95% Relative Humidity (Non-condensing)

• Operation Temperature: -10°C-50°C

Description

The Sako Sunon Pro series is a hybrid inverter or charger that combines the functions of a 100A MPPT solar charger and a battery charger to generate electricity. It has Maximum Power Point Tracking (MPPT) technology that can be used to extract the maximum available power from the PV module under certain conditions. It has a smart LCD setting which can set working mode, charge current, charge voltage etc. It combines solar systems, AC utilities, and battery power sources to provide uninterrupted power. Also protects against overload, short circuit and deep discharge.
