Microtek 1235 12V Solar PCU Inverter

Full SpecificationModel: Microtek Solar Pcu-1235 Capacity rated power: 935VA / 12 VCapacity maximum PV power support: 600 WPOutput power: 680WInput voltage standard range: 100 V ~ 300 VInput voltage narrow range: 180V ~ 260 VInput battery voltage: 12vInput frequency: 50HzEfficiency: 0.88%Output voltage: 230VOutput frequency: 50 Hz ± 0.5 HzOutput Waveform Pure Sine WaveSolar charger type: Pulse width modulationMax. solar panel current: 35 AmpsMains Re-Connect Voltage: 11.6 V + 0.3 V DCMains dis-Connect Voltage: 14.4 V + 0.3 V DCSolar UPS Overload: 110%Solar UPS Short Circuit: 300%Solar UPS Transfer Time: < 12>Grid Chg. Enable Mode: Luxury ModeGrid Chg. Disable Mode: Economy ModeDisplay: DigitalDimension: 39 x 38 x 20cmWeight: 11.8KgDescriptionMicrotek 1235/12V PCU solar inverter is a microcontroller DSPIC-based intelligent control design. It has dual charging modes such as main mode and solar mode. This inverter has smart pulse width modulation controlled multistage automatic trickle charging mode. It has LCD and graphical display indication which shows status and fault. This inverter has smart and faster overload sense and short-circuits protection. These inverters are easy to install, expensive, and can help reduce electricity bills. It is capable to run 4 Ceiling Fans, 7/8 LED Lights, or other TVs.

•
•
•
•
•

•
•
•
•
•

Details:

• Warranty
  2 Years & 4 Years Services

Full Specification

1. Model: Microtek Solar Pcu-1235
2. Capacity rated power: 935VA / 12 V
3. Capacity maximum PV power support: 600 WP
4. Output power: 680W
5. Input voltage standard range: 100 V ~ 300 V
6. Input voltage narrow range: 180V ~ 260 V
7. Input battery voltage: 12v
8. Input frequency: 50Hz
9. Efficiency: 0.88%
10. Output voltage: 230V
11. Output frequency: 50 Hz ± 0.5 Hz
12. Output Waveform Pure Sine Wave
13. Solar charger type: Pulse width modulation
14. Max. solar panel current: 35 Amps
15. Mains Re-Connect Voltage: 11.6 V + 0.3 V DC
16. Mains dis-Connect Voltage: 14.4 V + 0.3 V DC
17. Solar UPS Overload: 110%
18. Solar UPS Short Circuit: 300%
19. Solar UPS Transfer Time: < 12>
20. Grid Chg. Enable Mode: Luxury Mode
21. Grid Chg. Disable Mode: Economy Mode
22. Display: Digital
23. Dimension: 39 x 38 x 20cm
24. Weight: 11.8Kg

Description

Microtek 1235/12V PCU solar inverter is a microcontroller DSPIC-based intelligent control design. It has dual charging modes such as main mode and solar mode. This inverter has smart pulse width modulation controlled multistage automatic trickle charging mode. It has LCD and graphical display indication which shows status and fault. This inverter has smart and faster overload sense and short-circuits protection. These inverters are easy to install, expensive, and can help reduce electricity bills. It is capable to run 4 Ceiling Fans, 7/8 LED Lights, or other TVs.

Microtek 1235 12V Solar PCU Inverter

price

13,500 BDT15,500 BDTSave 2,000 BDT

sold_units 1

1

add_to_cart

buy_now

Details:

• Warranty
  2 Years & 4 Years Services

Full Specification

1. Model: Microtek Solar Pcu-1235
2. Capacity rated power: 935VA / 12 V
3. Capacity maximum PV power support: 600 WP
4. Output power: 680W
5. Input voltage standard range: 100 V ~ 300 V
6. Input voltage narrow range: 180V ~ 260 V
7. Input battery voltage: 12v
8. Input frequency: 50Hz
9. Efficiency: 0.88%
10. Output voltage: 230V
11. Output frequency: 50 Hz ± 0.5 Hz
12. Output Waveform Pure Sine Wave
13. Solar charger type: Pulse width modulation
14. Max. solar panel current: 35 Amps
15. Mains Re-Connect Voltage: 11.6 V + 0.3 V DC
16. Mains dis-Connect Voltage: 14.4 V + 0.3 V DC
17. Solar UPS Overload: 110%
18. Solar UPS Short Circuit: 300%
19. Solar UPS Transfer Time: < 12>
20. Grid Chg. Enable Mode: Luxury Mode
21. Grid Chg. Disable Mode: Economy Mode
22. Display: Digital
23. Dimension: 39 x 38 x 20cm
24. Weight: 11.8Kg

Description

Microtek 1235/12V PCU solar inverter is a microcontroller DSPIC-based intelligent control design. It has dual charging modes such as main mode and solar mode. This inverter has smart pulse width modulation controlled multistage automatic trickle charging mode. It has LCD and graphical display indication which shows status and fault. This inverter has smart and faster overload sense and short-circuits protection. These inverters are easy to install, expensive, and can help reduce electricity bills. It is capable to run 4 Ceiling Fans, 7/8 LED Lights, or other TVs.
