Microtek 2035 24V PCU Solar Inverter 1200Watt

বিঃ দ্রঃ - ক্যাশ অন ডেলিভারির ক্ষেত্রে কুরিয়ার খরচ অগ্রিম পেমেন্ট করতে হবে.Full SpecificationItem Solar IPSModel Solar PCU 2035 / 24VCapacity (Rated Power): 1735VA / 24VRated Power: 1200W (AC) Capacity (Maximum PV Power support): 1200 WPInput Voltage (Standard Range): 100V~300VInput Voltage (Narrow Range): 180V~260VNominal Input Battery Voltage: 24VOutput Frequency: 50 Hz ± 0.5 HzOutput Waveform: Pure Sine WaveSolar Charger Type: Power Width ModulationMax. Solar Panel Current: 35AmpMains Re-Connect Voltage: 23.2 V ± 0.3V DCMains Dis-Connect Voltage: 28.8 V ± 0.3V DCSolar UPS Overload: 110%Solar UPS Short Circuit: 300%Solar UPS Transfer Time: <12ms>Grid Chg. Enable Mode: Luxury ModeGrid Chg. Disable Mode: Economy ModeMains Input Voltage Range SelectionPV Mode ON/OFF Selection SwitchCharging Voltage Selection SwitchGrid Charging Enable /Disable SelectionPure Sine wave Regulated OutputDescriptionMicrotek 2035/24V Solar Inverter Built-in micro-controller DSPIC-based intelligent control design. It has dual charging modes like mains mode and solar mode. It also has a pure sine wave-regulated output. The charging mode of this electric signal converter is smart power width modulation controlled multistage automatic trickle. It has LCD and graphical display indicating status and error, smart and fast overload sense, and short circuit protection.

•
•
•
•
•

•
•
•
•
•

Details:

• Warranty
  2 Years & 4 Years Services

বিঃ দ্রঃ - ক্যাশ অন ডেলিভারির ক্ষেত্রে কুরিয়ার খরচ অগ্রিম পেমেন্ট করতে হবে.

Full Specification

Item Solar IPS

• Model Solar PCU 2035 / 24V
• Capacity (Rated Power): 1735VA / 24V
• Rated Power: 1200W (AC)
• Capacity (Maximum PV Power support): 1200 WP
• Input Voltage (Standard Range): 100V~300V
• Input Voltage (Narrow Range): 180V~260V
• Nominal Input Battery Voltage: 24V
• Output Frequency: 50 Hz ± 0.5 Hz
• Output Waveform: Pure Sine Wave
• Solar Charger Type: Power Width Modulation
• Max. Solar Panel Current: 35Amp
• Mains Re-Connect Voltage: 23.2 V ± 0.3V DC
• Mains Dis-Connect Voltage: 28.8 V ± 0.3V DC
• Solar UPS Overload: 110%
• Solar UPS Short Circuit: 300%
• Solar UPS Transfer Time: <12ms>
• Grid Chg. Enable Mode: Luxury Mode
• Grid Chg. Disable Mode: Economy Mode
• Mains Input Voltage Range Selection
• PV Mode ON/OFF Selection Switch
• Charging Voltage Selection Switch
• Grid Charging Enable /Disable Selection
• Pure Sine wave Regulated Output

Description

Microtek 2035/24V Solar Inverter Built-in micro-controller DSPIC-based intelligent control design. It has dual charging modes like mains mode and solar mode. It also has a pure sine wave-regulated output. The charging mode of this electric signal converter is smart power width modulation controlled multistage automatic trickle. It has LCD and graphical display indicating status and error, smart and fast overload sense, and short circuit protection.

Microtek 2035 24V PCU Solar Inverter 1200Watt

price

19,500 BDT22,500 BDTSave 3,000 BDT

sold_units 2

1

add_to_cart

buy_now

Details:

• Warranty
  2 Years & 4 Years Services

বিঃ দ্রঃ - ক্যাশ অন ডেলিভারির ক্ষেত্রে কুরিয়ার খরচ অগ্রিম পেমেন্ট করতে হবে.

Full Specification

Item Solar IPS

• Model Solar PCU 2035 / 24V
• Capacity (Rated Power): 1735VA / 24V
• Rated Power: 1200W (AC)
• Capacity (Maximum PV Power support): 1200 WP
• Input Voltage (Standard Range): 100V~300V
• Input Voltage (Narrow Range): 180V~260V
• Nominal Input Battery Voltage: 24V
• Output Frequency: 50 Hz ± 0.5 Hz
• Output Waveform: Pure Sine Wave
• Solar Charger Type: Power Width Modulation
• Max. Solar Panel Current: 35Amp
• Mains Re-Connect Voltage: 23.2 V ± 0.3V DC
• Mains Dis-Connect Voltage: 28.8 V ± 0.3V DC
• Solar UPS Overload: 110%
• Solar UPS Short Circuit: 300%
• Solar UPS Transfer Time: <12ms>
• Grid Chg. Enable Mode: Luxury Mode
• Grid Chg. Disable Mode: Economy Mode
• Mains Input Voltage Range Selection
• PV Mode ON/OFF Selection Switch
• Charging Voltage Selection Switch
• Grid Charging Enable /Disable Selection
• Pure Sine wave Regulated Output

Description

Microtek 2035/24V Solar Inverter Built-in micro-controller DSPIC-based intelligent control design. It has dual charging modes like mains mode and solar mode. It also has a pure sine wave-regulated output. The charging mode of this electric signal converter is smart power width modulation controlled multistage automatic trickle. It has LCD and graphical display indicating status and error, smart and fast overload sense, and short circuit protection.
